- Arms from 2 up to 6 mt
- Irreversible, intensive use
- Powder coated steel structure
- Engine housing in cast aluminum
- Steel and cast iron gears
- High performance electric motor
- Lithium grease lubrication of mechanical parts
- Microswitches in opening and closure
- Balance with spring
- Optional round arm standars- rectangular arm optional
- Handle emergency release for 230 v – mechanical release with key for 24 v
- Max lenght arm 6m – kit led optional
- Easy programming software
- Control unit with receiver and built-in aerial
- Anti squashing system and slowing down function (en 12453)
- Electronic torque control
- Anti black-out battery kit
Models and Codes
- 1445 | BERTA 230V: Barrier – Control unit – Arms from 3 to 6 mt
- 1445/2 | BERTA 230V FAST: Barrier – Control uni – Arms from 2 to 4 mt
- 1446 | BERTA 24V: Barrier – Control uni – Arms from 3 to 6 mt
- 1446/3 | BERTA 24V FAST 3000: Barrier – Control uni – Arms from 2 to 4 mt
Performance requirements
- Operating cycle semi-intensivo 230Vac, intensivo 24Vcc
- Frequency of use 50% (230Vac) – 100% (24Vcc)
- Opening 10 sec. (BERTA) – 5 sec. (BERTA FAST)
Technical features
| BERTA 230Vac | BERTA 230 FAST | BERTA 24Vcc | BERTA 24 3000 RPM | |
| POWER SUPPLY | 230 Vac | 230 Vac | 24 Vcc | 24 Vcc |
| MAX LENGHT ARM | 6 MT | 4 MT | 6 MT | 4 MT |
| OPENING TIME | 10 SEC | 5 SEC | 10 SEC | 5 SEC |
| ABSORBED POWER | 250 W | 250 W | 60 W | 60 W |
| OPERATOR WEIGHT | 45 KG | 45 KG | 45 KG | 45 KG |
| NOISE LEVEL | < 30 DBA | < 30 DBA | < 30 DBA | < 30 DBA |
| ENVIRONMENTAL CONDITIONS | -20/+55° C | -20/+55° C | -20/+55° C | -20/+55° C |
| DEGREE OF PROTECTION | IP44 | IP44 | IP44 | IP44 |
