TONDO – Operator for shutters

  • Weight up to180 KG
  • New design
  • Quick installation even on existing shutters
  • Irreversible
  • Manual release
  • Electrobrake
  • Mechanical limit switch built-in, easy adjustable
  • Fast, reliable and silent
  • Power supply 230 Vac

Models and Codes

  • 1000043/R  |  TONDO 140: Roller shutter operator 140 kg with electrobrake – Ø 48-60
  • 1000043/B  |  TONDO 180: Roller shutter operator 180 kg with electrobrake – Ø 48-60

Performance requirements

A
B
C
TONDO 140
60/48 MM200/220 MM320 MM
TONDO 18060/48 MM200/220 MM320 MM

Technical features

TONDO 140
TONDO 180
POWER SUPPLY
230 VAC230 VAC
LIFTING FORCE140 KG180 KG
CONDENSER18 UF22 UF
AVERAGE ABSORPTION2,5A2,5A
ABSORBED POWER 520 W700 W
RPM RING9/MIN9/MIN
OPERATOR WEIGHT8 KG10 KG
ENVIRONMENTAL CONDITIONS-20/+85° C-20/+85° C
LIMIT SWITCH6 MT6 MT
